Turbo Kit Includes:

1.) *** Turbo Next Gen PTE 7480 Sportsman or Next Gen R 6870 Sportsman***
2.) Wastegates 2x Turbosmart 45mm
3.) Coupler 3” (x1)
4.) Manifold True Twin Scroll T4 Divided Dual Wastegate
5.) *** 4″ Down Pipe ***
6.) V-Band Clamp for Down Pipe
7.) Dump Tubes (X2)
8.) *** Intercooler Piping with 3 Weld Fittings/ 1 BOV Flange w/ V-Band Sportsman Flange ***
9.) *** V-Band Clamp for Intercooler Piping ***
10.) Turbo Studs & Turbo Gasket (Trimmed Studs)
11.) 10AN Nylon Braid Hose 2ft.
12.) 10AN Hose end Fitting 1 X 45Degree
13.) 10 AN Hose end fitting 1 X 90 degree
14.) Stainless Braid Oil feed Line 2ft. Vibrant
15.) Silicon Vacuum Hose 6ft.
16.) 4AN to 4AN 90 Degree Oil Feed Fitting
17.) Oil Return Block Off Fitting
18.) Oil Feed Block Off Fitting
19.) Oil Return Block Fitting 10AN (use factory bolt and O-ring)
20.) Oil Feed Block Fitting 4AN (use factory bolt and O-ring)
21.) Drain Block Off Front (use factory bolt and O-ring)
22.) Drain Block Off Cap (Factory Style)
23.) Turbo Oil Drain Fitting / with Bolts and O-Ring (x2)
24.) M6x12mm Bolts for Intercooler Piping (X3) [1x for map, 2X for Rad Bracket]
25.) Heat Tape (20 Inches)
26.) Vacuum T Fittings (X2)
27.) KLM Stickers
28.) 1/8″ NPT Plugs (x2)
29.) O2 Sensor Block Off (X2)
30.) Billet Throttle Body Adapter

Coolant Overflow Relocation Kit:
31.a) Relocation Bracket
31.b) 180° Hose
31.c) 90° Hose (22in cut form 90)
31.d) Aluminum Barb Fitting
31.e) 1/4″ Heater Hose (thicker than vacuum hose) 45in
31.f) Brown and Black Wire 5ft.
31.g) 5ft. Wire Loom
31.h) 4X Wire Connector
31.i) 4X 1/4″ Hose Clamps
31.j) 4X 5/8″ Hose Clamps
32.) Turbo drain and feed line heat sleeve
33.) Vacuum line heat sleeve

KLM Source Options

Configuration required: this KLM item has more option groups than Shopify can safely represent as native variants. Contact BMD Performance to confirm the final configuration and price.

• Turbo
  • No Turbo
  • Precision NEXT GEN 6880 (+$3159.28)
  • Precision NEXT GEN 7480 (+$3350.78)
  • Precision NEXT GEN 7680 (+$3973.16)
  • Precision NEXT GEN 8080 (+$3973.14)
  • Precision NEXT GEN 8085 (+$4140.70)
  • Precision NEXT GEN 8385 (+$4212.52)
  • Precision NEXT GEN 8685 (+$4382.23)
  • Precision NEXT GEN R 73.9 (+$4140.70)
  • Garrett G42-1200 (+$2571.27)
  • Garrett G45-1475 (+$4649.30)
  • Garrett GXR42-68 (+$3261.20)
  • Garrett GXR45-73 (+$4226.23)
  • Turbosmart 7880 Pro Cover (+$3639.99)
  • Turbosmart 8280 Pro Cover (+$3639.99)
• KLM Catch Can Kit
  • Yes - $466.94 (+$466.94)
  • No
• KLM Turbo Blanket
  • Yes - $79.99 (+$79.99)
  • No
• KLM Turbo Guard
  • Yes - $99.99 (+$99.99)
  • No
• Select One
  • M2 / M3 / M4
  • X3M / X4M
